IB820FH-32

Ibase IB820FH-32 Full Sized Embedded CPU Boards

● Supports Pentium 4 / Celeron® processors

 Up to 3.06GHz, 400/533MHz FSB

 ● DDR DIMM x 2, Max. 2GB

● Intel  845GV integrated VGA for CRT support

● ICH4 10/100 BaseT Ethernet

 ● 6 x USB 2.0, ISA High Drive, Watchdog timer

 ● DiskOnChip, 1 x MicroPCI, PCI to ISA bridge

The IB820 Pentium 4 Full Size PICMG CPU Card incorporates the

Intel® advanced 845G Chipset Memory Controller hub and supports

478-pin Intel Pentium 4 processors of 1.3GHz and up to 3.06GHz+ with

FSB 533MHz/400MHz. IB820 supports the Pentium 4 processor with

256-KB L2 cache and the Pentium 4 processor with 512-KB L2 cache on

0.13 micron process.

The I/O functions are on IB820 integrated onto the ICH4. It supports

either the integrated graphics device (IGD) on the GMCH or an external

graphics device on AGP. The IGD has 3D, 2D, and video capabilities. The

system memory size can be up to 2 GB, using the two DDR sockets on

board. Six USB ports are supported with the USB 1.1/2.0 standard.
